drum type wood chipping machine

The drum chipper is the special equipment for producing the perfect chips. It is used in paper plants, particle board plants, fiber-broad plants, chip production and export bases. By which, the logs and small wood are cut into high quality with even length and uniform chip thickness.

It is also suitable for chipping of branches, twigs and planks. Cutting the main raw material of small diameter wood ,timber harvesting ,processing residues (such as branches ,twigs, slab, the log core veneer , waste),can also be used for cutting non-wood raw materials (such as sugar cane , reed , bamboo etc).

The chip length is different in accordance with the requirements of paper plants, particular broad and fiber-board industries. In order to meet this need, we have improved different kinds of drum chippers recently, and the new type machines have more advantages.

Model	BX-313	BX-315	BX-316	BX-318	BX-318	BX-2113
Main Power (kw)	30	45	55	110	110	220
Q鈥橳Y of flying blades(pcs)	4	4	4	4	5	4
Opener size (mm)	300x150	400x170	540x220	680x270	680x270	700x400
Input max diameter(mm)	130	150	200	250	250	300
Length of chips (mm)	10-20	10-20	10-20	15-25	10-15	15-20
Capacity (T/H)	2-3	3-5	8-12	15-25	15-25	25-35
Dimension of machine (m)	2.5x1.7 x1.3	2.6x1.8 x1.4	3.1x2 x1.5	3.5x2.18 x1.8	3.5x2.18 x1.8	3.68x2.45 X2.05
Weight of machine (kg)	2200	3380	4680	8320	9100	11850
Feeding belt conveyor (m)	4x0.3	4x0.4	6x0.55	6x0.7	6x0.7	8x0.72
Discharging belt conveyor (m)	10x0.4	10x0.5	10x0.6	10x0.8	10x0.8	10x0.8
